1350—1550 MHz 16 dBi GSM L-Band Yagi Antenna

Description

Introducing the Y1500-16 L-Band Yagi Antenna: A High-Gain Link Antenna

The Y1500-16 Yagi L-band high-gain link antenna is crucial in the Aeronautical Radionavigation Service (ARNS).

1. L5 Radionavigation Signal:
The L5 radio-navigation signal was specifically designed to support safety-of-life transportation and other high-performance applications.

2. Frequency Allocations:
The L-band is allocated for various aeronautical communication and navigation services, including the aeronautical mobile (route) service and aeronautical radio-navigation service.

3. Transition Support:
Introduction of L–DACS (L-band Digital Aeronautical Communications System) in the L-band can support transitioning from Aeronautical Information Services (AIS) to Aeronautical Radio Navigation Services.

The L-band in ARNS is essential for ensuring safe and efficient aircraft operation through reliable communication and navigation systems.

16 dBi 1350—1550 MHz

The Y1500-16 Yagi antenna is a powerful and versatile shrouded high-gain link antenna designed to deliver exceptional performance in various communication applications.

Here are some key features and characteristics of the Y1500-16 Yagi antenna, highlighting its design, functionality, and applications.

Shrouded Design for Weatherproof Protection

One of the distinctive features of the Y1500-16 Yagi antenna is its shrouded design, which provides adequate weatherproof protection for the driven element. This design element enhances the antenna’s durability and resilience, making it suitable for outdoor installations in diverse environmental conditions. Whether exposed to rain, wind, or other elements, the fully shrouded elements ensure the antenna remains completely protected, maintaining its performance over time.

High Front-to-Back Ratio

The Y1500-16 Yagi antenna is engineered to deliver a high front-to-back ratio, enabling it to effectively reject signals from unwanted directions. This characteristic is particularly valuable in scenarios where minimizing interference and maximizing signal clarity are essential. By offering a high front-to-back ratio, the antenna enhances the quality and reliability of communication links, making it a valuable asset in demanding operational environments.

DC Grounding of All Metal Parts

All metal parts of the Y1500-16 Yagi antenna are DC grounded to ensure robust performance and safety. This feature mitigates the risk of electrical surges, static build-up, and interference, safeguarding the antenna and the connected communication equipment. By grounding all metal components, the antenna offers enhanced protection against electrical disturbances, contributing to the overall stability and longevity of the communication system.

N Female Connector

The Y1500-16 Yagi antenna is equipped with an N female connector, providing a reliable and secure interface for connecting to compatible communication devices and systems. The N-type connector is widely recognized for its durability, impedance-matching capabilities, and suitability for high-frequency applications. With the N-type female connector, the Y1500-16 Yagi antenna ensures a robust and efficient connection, facilitating seamless integration into communication networks.

Applications

The Y1500-16 Yagi antenna’s combination of high gain, weatherproof design, high front-to-back ratio, and DC grounding makes it well-suited for a range of applications, including:

• Long-range point-to-point communication links
• Wireless communication systems in challenging outdoor environments
• Communication infrastructure deployments requiring reliable performance in varying weather conditions
• Remote monitoring and control systems that demand consistent connectivity and signal integrity

The Y1500-16 Yagi antenna is a durable, high-performance solution for establishing robust communication links in diverse settings. Its shrouded design, high front-to-back ratio, DC grounded metal parts, and N(f) connector collectively contribute to its reliability, making it a valuable asset for applications that demand dependable, weather-resistant communication capabilities.

Webb manufactures these antennas on demand. If you have any questions or need further details, please contact us.

Additional information

Weight	3 kg
Dimensions	150 × 14 × 14 cm
Part Number	BJY1500-16
Band Selector	Cell
Frequency Band	1350 — 1550 MHz
Nominal Gain	16 dB
