Attenuator N Plug-Jack 10d 1 GHz 1W

Description

N Attenuators 10 dB; 1 Watt; ≤ 1 GHz; VSWR ≤ 1,2/1 GHz; Inner conductor gold plated

The Telegärtner TestLine attenuators are used to weaken RF signals. Up to a frequency of 6 GHz, a precise signal attenuation of 3, 6, 10 or 20 dB depending on type is achieved. Application fields for attenuators in test and measurement are where the RF performance needs to be set at certain levels.

Remarks: inner conductor gold plated
Type: m-f
Max. Frequency: 1 GHz
Max. Power: 1 W
Return Loss: typ.: 1 GHz: -21 dB
Attenuation: 10 dB

100024160 >
( Old item number J01026A0007)
