TRD GPS Train Antenna

GPS, Train Antenna, Low Profile

TRD GPS Train Antenna

In stock
0 out of 5

TRD Low Profile Antennas are rugged and designed for use on locomotives, buses or trucks.
The TRD GPS Antenna option covers:
with one connector.
The high impact cover makes it ideal for harsh environments.

Availability: 3 in stock SKU: A10AA1366A Categories: , Tag: Brand:
Compare products Compare products


The TRD GPS Train Antenna is a low-profile antenna that is robust and designed for applications on locomotives, buses, or trucks. The antenna covers the GPS band with one connector. It has a high-impact cover that makes it ideal for harsh environments.

The antenna has the following specifications: an operating frequency of 1575 MHz and a nominal gain of 26 dBic (relative to an isotropic circularly polarized antenna). It has a characteristic impedance of 50 Ohm and a maximum noise figure of 2 dB. It radiates its power equally in all directions perpendicular to its axis.

The amplifier inside the TRD GPS Train Antenna needs to be powered by a DC supply of 3 – 5 V. The antenna can withstand wind velocities of up to 300 km/h. The antenna is only available in the color white. It weighs less than 1 kg and has a temperature range of between -30 degrees Celsius and 75 degrees Celsius.

The antenna is right-hand circularly polarized. This means that the electric wave rotates clockwise in a direction perpendicular to the optical axis. Both transmitting and receiving antennae must have the same polarization so that power losses in the RF system do not occur and to ensure maximum efficiency of the RF system.

Additional information

Weight 1 kg
Dimensions 21 × 12 × 12 cm
Part Number


Band Selector

Additional Band Option


Nominal Gain
